Here at Pro Audio LA, we specialize in complete console patchbay and wiring solutions. This is just an example of a wiring solution for API The Box. It's set up for stereo operation, and includes cabling to connect every connection on the console. All cables are a default length of 15 feet with 18 inch fanback. Contact us for custom lengths, fanbacks, etc.
This package includes 1 Audio Accessories MiniShorti patchbay and 11 Dsub snakes. 14 points of the patchbay will be available for your other equipment.
Premium finish includes metal DB25 hoods and mesh techflex on any fan snakes.
API The Box Cabling package includes the following items:
- (1) 96 Point DB25 to TT Patchbay
- (48) 2 Ft Molded Mini-Quad Gold Plated TT Patch Cables
- (2) 15 Ft DB25 to DB25 for Summing Inputs 1-16
- (2) 15 Ft DB25 to 1/4" TRS for Insert Sends 1-16
- (2) 15 Ft DB25 to 1/4" TRS for Insert Returns 1-16
- (1) 15 Ft DB25 to DB25 for 2 Track Inputs
- (1) 15 Ft DB25 to XLR-Male/1/4" TRS for Mic 1-4, Line 5-8 Inputs
- (1) 15 Ft DB25 to DB25 for Aux Cue Outputs 1-6
- (1) 15 Ft DB25 to DB25 for 1-4 Direct Out (post fader), 5-6 Insert Sends Channels 1-2, 7-8 Preamp Out 3-4
- (1) 15 Ft DB25 to 1/4" TRS 1-2 for Insert Return Channels 1-2, 3-4 500 Slot Inputs 3-4, 5-6 for Program Bus Return, 7-8 XLR-Male Bus Sum Input
- (1) 15 Ft DB25 to 1/4 TRS 1-2 for Insert Sends Channels 3-4, 3-4 for Program Bus Send, 5-6 XLR-Female for Program Bus Out
- (1) 15Ft 4 Channel Wallbox 1/4" TS 1-4 for Direct In's 1-4 (wired unbalanced for instruments)
- (4) 15 Ft Mogami 2549 XLR cables for Speaker Feeds Main Out, Alt Out
Pro Audio LA Patchbay and Cable Labeling Service:
We offer full labeling solutions for all our packages. As part of this package, we will do a workflow and system design consultation and label the cables and patchbays to your spec.
All snakes have a standard 18 Inch Fan-back (included in 15 ft total length)
Contact us if you'd like a longer fan. Premium finish cables available by selecting the Premium option.
